SHARE SLAM S10

Manual laser scanner (SLAM)

LiDAR FOV laser unit
Compact and lightweight (1kg)
Range up to 70m
Up to 200,000 pts / second
Absolute accuracy of 5cm, without control points
Relative accuracy of 1cm
Dot cloud density < 1cm
2 x 12 Mpx panoramic cameras
Includes centimetre-accurate GNSS RTK module
Up to 90 minutes battery life
RGB point cloud display, in real time
Includes field APP and post-processing software

DESCATALOGADO: (Vea aquí la nueva versión S20)

Share SLAM S10

Description
Specifications

Description

Handheld laser scanner for fast measurements and LiDAR point cloud creation. The most compact and lightest RTK SLAM.

Video 1. Indoor test. Pure SLAM mode:

<span style="display: inline-block; width: 0px; overflow: hidden; line-height: 0;" data-mce-type="bookmark" class="mce_SELRES_start"></span><span style="display: inline-block; width: 0px; overflow: hidden; line-height: 0;" data-mce-type="bookmark" class="mce_SELRES_start"></span>

Video 2. Outdoor test. RTK mode:

<span style="display: inline-block; width: 0px; overflow: hidden; line-height: 0;" data-mce-type="bookmark" class="mce_SELRES_start"></span><span style="display: inline-block; width: 0px; overflow: hidden; line-height: 0;" data-mce-type="bookmark" class="mce_SELRES_start"></span><span style="display: inline-block; width: 0px; overflow: hidden; line-height: 0;" data-mce-type="bookmark" class="mce_SELRES_start"></span>

Specifications

PHYSICAL PARAMETERS

Weight	1.01 kg (with battery)
Battery	14.4V 3150 mAh
Charge	USB-C 30W (Fast Charging)
Storage	256 Gb (SD card)
Level of protection	IP54
Working temperature	-20 ℃-55 ℃
Transport platform	Manual
Working modes	Pure SLAM, Checkpoints and RTK

LASER UNIT

Detection range	40m@10%, Maximum range 70m
Relative accuracy	1 cm
Absolute precision	5 cm
LiDAR FOV	H: 360º - V: 52º H: 360º - V: 52º H: 360º - V: 52º
LiDAR class	Class 1
Point rates	200,000 points/sec

GNSS UNIT (POS)

RTK	Integrated
RTK accuracy	H: 0,8cm + 1ppm - V: 1,5cm + 1ppm

CAMERAS

Resolution	2 x 12 Mpx
Field of vision	Horizontal: 360° x 270° Horizontal: 360° x 270° Horizontal: 360° x 270° Horizontal: 360° x 270
Shooting mode	Isochronous

OTHER CHARACTERISTICS

Dot cloud format	.las, .pcd, .ply
Processing method	Real-time and Post-processing
APP phone	Real-time RGB point cloud support (Android and iOS)
PC software	Supports one-click processing for RGB point clouds and image overlay and point cloud panoramas
